Grille Machine

Overview

Grille machine is a solid-liquid separation equipment that can continuously remove impurities in fluids. It is an indispensable specialized equipment in the production processes of urban sewage treatment, water plants, power plant inlets, textile, food processing, papermaking, leather and other industries. It is a commonly used solid-liquid screening equipment in China.

Product Description

Structural features:
Continuous cleaning action and high separation efficiency; Compact structure, simple electrical control, and high degree of automation; Good corrosion resistance, low energy consumption, and no noise.

Technical parameters:

Model	Parameters	Numerical value
SSHF 300-2000	installation angle	60°- 80°
	running speed（m/min ）	约2
	Total width of equipment W1（mm）	850-2290
	Total width of equipment W1（mm）	300-2000
	power（KW）	0.75-1.5
	Medium temperature（℃）	60°- 100°
	Length of guide groove L（mm）	1500
	Rake tooth pitch（mm）	100
	The height of slag discharge H1（mm）	1500-1800
	Groove depthH（mm）	1000-1200（User defined）
	Total height of equipment H0（mm）	H+H1+1350
