Mobile Welding Smoke Purifier

Product Description

Working principle:
Through the gravitational force of the fan, the welding smoke exhaust gas is sucked into the equipment inlet through the universal vacuum hood. A flame arrester is installed at the equipment inlet, and sparks are blocked by the flame arrester. The smoke and dust gas enters the settling chamber. Using gravity and upward airflow, the coarse dust is first directly lowered to the ash hopper, and the fine smoke and dust are captured on the outer surface by the filter element. After being filtered and purified by the filter element, the clean gas flows into the clean room from the center of the filter element, The clean air is further purified by adsorption through an activated carbon filter and discharged through the air outlet to meet the standard.
